AP1200-D4
- 4 × 1300W @ 8Ω
- 4 × 1900W @ 4Ω
- 4 × 2500W @ 2Ω
D SERIES
D SERIES High Efficiency.
Four-Channel Power.
High-power 4-channel Class D professional amplification engineered for bars, audio rooms, touring systems and theatres, with wide-voltage operation and comprehensive protection.
4-Channel Power1300W per channel at 8Ω, 1900W at 4Ω and 2500W at 2Ω.
Class D EfficiencyHigh-efficiency Class D amplifier circuit designed for professional high-output systems.
Wide Voltage OperationPatented technology is specified to operate across AC 80–265V.
Protection SystemSoft start, overload, overheat, short-circuit, DC-output and peak-limiting protection.
D SERIES MODEL
OVERVIEW
The AP1200-D4 is a 4-channel high-efficiency professional power amplifier intended for applications including bars, audio rooms, touring and theatres. The supplied specification sheet describes a Class D amplifier circuit, high-performance ring transformer, 120A high-current high-frequency MOS transistor output path and a specially designed output LC circuit. It also specifies wide-voltage operation and multiple protection functions for demanding professional use.
4 ChannelsIndependent high-power output channelsClass DHigh-efficiency professional amplifier circuitLC Output CircuitDesigned for full and detailed soundWide AC RangeSpecified operation from AC 80–265VMulti ProtectionOverload, thermal, short, DC and peak protection
Professional BuildDurable brushed aluminium front panelTECHNICAL SPECIFICATIONS
| Specification | AP1200-D4 |
|---|---|
| Channel number | 4CH |
| 8Ω output power / channel | 1300W |
| 4Ω output power / channel | 1900W |
| 2Ω output power / channel | 2500W |
| 8Ω bridged power | 3500W |
| 4Ω bridged power | 3800W |
| Frequency response | 20Hz–20kHz |
| Total harmonic distortion | <0.03% |
| Channel separation | <65dB |
| Signal noise ratio | 100dB(A) |
| Slew rate | 40V/μs |
| Damping factor (100Hz) | >800:1 |
| Net weight | 20kg |
| Packing dimensions | 580 × 520 × 185 mm |
| Operating voltage | AC 110–220V / 50–60Hz |
Specifications reproduced from the supplied AP1200-D4 product sheet. The same sheet separately states patented wide-voltage operating capability of AC 80–265V.
APPLICATIONS
Live Sound / Concerts
Touring & Events
Fixed Installations
Theatres & Auditoriums
Houses of Worship
Clubs & Venues
DOWNLOADS
AP1200-D4 DatasheetAP1200-D4 / AP1200-D4 / AP1200-D4 / AP1200-D4⇩
DatasheetTechnical parameters are included in the user manual.
BrochureNot supplied yet
